Solution for pump electrophoretic paint
Product Introduction :
HL-1605LB/HL-1701A Black Cationic Epoxy Electrocoat for auto is a
new generation electrophoretic coating researched and developed by
HLS Paint (Shanghai) Co., Ltd.
It represents modern technology of cathodic electrophoretic
coatingthat isenvironment-friendly withhigh propertyandlow cost.
Such coatingdoesnot contain heavy metal like lead, tin, cadmium and
mercury etc. It is a two-component, water-dispersed
resin,meanwhile, it took in features of previous products, andcan
adapt galvanized steel sheet perfectly,almost canbe applied to
foundation coating of all metal
such as: cold and hot rolled steel sheet, galvanized steel sheet,
aluminum products, zinc-aluminum alloy sheet and stain less steel
sheet etc.
This product features shown below :
The appearance of the coatingis flat,delicate,smooth
| Good stability of bath can adaptable for a longer updating cycle |
Strong anti-corrosion properties, good salt spray resistance
workpiece edge
| Excellent leveling coating,good bonding for ceand compatibility
with plastic powder |
The main component Matrix resin:
1,Additives: surface active agent, prevent shrinkage cavity agent
2,Pigment: Titanium pigment, carbon black, kaolin, antirust pigment
3,Curing agent: totally enclosed multi-isocyanates
4,Matrix resin:polyurethane modified epoxy resin
Bath on site management project :
Good bath data and coating quality, from the strict parameters
management and maintenance of equipment, production line according
to its own reality time situation, can have different management
project and specifications, recommend the construction parameters
see the table below for reference:
| Classification | Project | Control Data | Testing frequency |
| New bath | Anolyte |
| Electrophoresis tank | Ratio | 1:(4-6) | -- | |
| Ripening time | 24-48 | -- | |
| Solid ( 120 ℃ /1h ,% ) | 14±4 | -- | once a day |
| PH | 5.7-6.0 | 2.0-3.5 | once a day |
| Conductivity ( μs/cm ) | 1200±400 | 1500±700 | once a day |
| P/B | 0.08-0.15 | once a week |
| Solvent content (%) | 0.5-1.8 | once a week |
| Liquid level Fall head (cm ) | 10-15 | once a day |
| ED voltage( V ) | 0-300 | once a day |
| Break voltage ( V ) | ≥320 | once a week |
| Bath temperature ( ℃ ) | 28-35 | once a day |
| ED time( S ) | 60~180 | once a day |
| UF － 1 Tank | Solid content (%) | ≤2.0 | once a day |
| UF － 2 Tank | Solid content (%) | ≤0.8 | once a day |
| Baking furnace | Provisions furnace temperature( ℃ ) | 180-190 | once a day |
| Curing conditions | Drying temperature |
(175-185) ℃×(15-20)min (With content holding time) | once a day |
Construction equipment
Cathodic electrophoretic coating construction in the
electrophoresis tank, so need to have the following equipment:
Electrophoresis tank
Circulation devices (including filter, fill the paint device)
DI water equipment
DC power supply and the power supply unit
Anode box (tube) and circulation device
Ultrafiltration device
Cleaning devices
Heat exchanging equipment
Curing device
Customers in the pump industry :
