    Anticorrosive E Coating Car Body With Alcohol Ether / Carbon Black Ingredients

    Ask Lasest Price
    Brand Name : HAOLISEN
    Model Number : HLS-5702LB/HLS-5780
    Certification : IATF16949 , ISO9001
    Price : Negotiation
    Supply Ability : 200 Tons Per Day
    Delivery Time : 30-60 Days
    • Product Details
    • Company Profile

    Anticorrosive E Coating Car Body With Alcohol Ether / Carbon Black Ingredients

    Solution for the truck electrophoresis paint.


    Product Introduction


    HLS-5702LB/HLS-5780 Gray Cationic Epoxy Electrocoat for auto is the 7th generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd. in cooperation with Germany HS International Chemical Industry Group. It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal, such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products, zinc-aluminum alloy sheet and stainless steel sheet

    This product features shown below: 


    High throwing power, internal and external uniformity.Coating fullness of good, better substrate hiding .
    suitable for auto body industry, such as cars, truck,SUV and other models.

    Main ingredients


    Neutralizing agent: organic acid
    Solvent: alcohol ether
    Curing agent: Fully enclosed multi isocyanate

    Filling tank proportion and method


    Ripening conditions

    Sample quantity3000~3500g
    Container4L (Diameter 16cm)
    Tank temperature30±2℃
    Time24~48Hr
    Mixed conditionsimpeller diameter 8cm (speed 200rpm)


    Construction equipment


    Cathodic electrophoretic coating construction in the electrophoresis tank, so need to have the following equipment: 


    Electrophoresis tankCirculation devices (including filter, fill the paint device)DI water equipment
    DC power supply and the power supply unit Anode box (tube) and circulation device Ultrafiltration device 
    Cleaning devicesHeat exchanging equipment Curing device

    Graph of the curing conditions


    Baking temperature(℃)160165170175180185190195
    Baking time(min)30252018151286

    Anticorrosive E Coating Car Body With Alcohol Ether / Carbon Black Ingredients
